B-EX6T1-GS/TS12 |
B-EX6T3-GS/TS12 |
| CHARACTERISTICS |
| Printhead |
Near-edge head |
Near-edge head with cool down bar |
| Dimensions |
331 (W) x 480 (D) x 310 (H) mm |
| Weight |
20 kg |
| User interface |
Graphic LCD, 2 x LED, 10 x key |
| Operating Temperature |
5 - 40°C (41 - 104°F) / 25 - 85% non-condensing
relative humidity (RH) |
| Standard Interface |
USB 2.0, LAN 10/100 Base, IPv6, USB Host/RTC, |
| Optional Interface |
RS232, Centronics, Wireless LAN, EX I/O |
| Memory |
System (Flash Memory) 64MB, SRAM 32MB |
| Power Supply |
AC 100 to 240V, 50/60 Hz |
| PRINT |
| Method |
Direct thermal / Thermal transfer |
| Resolution |
203/305 dpi ( 8/12 dots/mm) |
| Maximum Print Width |
160mm |
| Maximum Print Length |
1490mm |
| Maximum Print Speed |
305 mm/second (12 ips) |
| Ribbon Save Function |
Yes |
No |
| Barcodes |
UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Postnet, RM4SCC, KIX-Code, Customer Barcode, GS1 Databar |
| 2D Codes |
Data Matrix, PDF417, MaxiCode, QR Code, Micro PDF417, CP Code, AZTEC Code, GS1 QR Code |
| Font |
Bitmap font, Outline font, Price font, Optional TTF, OTF, Writable characters |
| RIBBON |
| Type of ribbon |
Edge head type |
Flat head type |
| Maximum Ribbon Width |
170mm |
| Maximum Ribbon Length |
800 m (Up to 5 inch width) |
600 m |
| MEDIA |
| Paper Alignment |
Center |
| Backing Paper Width |
50-165 mm |
| Label Thickness |
0.13-0.17 mm |
| Tag Thickness |
0.08-0.25mm |
| Paper Roll |
200 mm (7.9") |
| SOFTWARE & CONNECTIVITY |
| Printer Driver |
Windows 10/8.1 (32/64 bit), Windows Server 2016, Windows Server 2012 R2/Windows Server 2012, SAP |
| Language Mode |
TPCL, ZPL II, BCI (function) |
| OPTIONS |
|
Disc cutter, Peel-off module, Fan fold guide, RS232, Centronics, Wireless LAN, EX I/O, RFID Kit* |
